DL337 LED Disk Light

A two-in-one DOB downlight solution that can be retrofitted into an existing can or surface mounted to a 3.5inch and 4inch junction box. The smooth aluminum housing makes the fitting more elegant, and the PC cover providing smooth, even light with no dark spots. Perfect for residential or commercial applications with exceptional RA90. It is available for single CCT or changeable CCT 3000K+4000K+5000K, wet location which suit for a wider application areas.

Eco design with DOB (driver on board) technology.
High color rendering, RA90.
Adjustable available with 3000K+4000K+5000K.
120V triac dimmable.
Installation way: Recessed, surface mounted.

Code No.	DL337-4-10W	DL337-6-14W
Dimension(Inch)	Ø5-5/16"*1-1/16"	Ø7-5/16"*1-3/16"
Cutout (Inch)	–
Watt(W)	10W	14W
Rated Input Voltage(V)	AC120V
Input Voltage(V)	AC110-130V
LED Module Input	–
Light Source	SMD
SDCM	-
CCT(K)	1-CCT: 3000K/4000K/5000K \|\| 3-CCT: 3000K + 4000K + 5000K
CCT Selection DIP Switch	-
CRI	90
Beam Angle (°)	120°
UGR	–
LED Driver	Built-in
Dimming Option	Triac
Sensor	-
Emergency Kits	NO
Electrical Class	With Ground
Ingress Protection (IP Rating)	Damp
Impact Resistance (IK Rating)	NA
Product Finishing(Base)	White
Materials of Optics	PC
Materials of Housing	Iron
Lifetime (hr)	50000H
Glow wire test (℃ )	850
Operating Temp. (℃ )	-20℃ ~40℃
Storage Temp. (℃ )	-20℃ ~65℃
Installation	Surface mount/Recessed
